Amass XT60-F to M8 O-Ring Terminal Lug – Custom Cable Assembly

Original price was: $4.80.Current price is: $3.55.

Sale!
SKU: 1749946467 Category:
Share
  • Single-ended pigtail cable terminated with an Amass XT60 female connector on one end and two crimped M8 (5/16 in) tinned copper ring terminal lugs on the other, configured for direct stud-mount termination at a battery post, busbar, contactor, or solar charge controller terminal block.
  • Available in 10, 12, and 14 AWG with high-strand silicone insulation (65 C to +200 C) or PVC where cost dominates, in stock lengths of 6, 12, 18, 24, and 36 inches, with red/black polarity coding, color-coded heat-shrink barrels at the lug, and optional M5, M6, M8, or M10 ring stud sizes.
  • XT60 connector rated 30 A continuous and up to 60 A peak at 500 V DC per Amass X-series specification, mated to UL-listed tinned copper compression ring terminals making the connector the current-limiting element of the finished pigtail at 30 A continuous.
  • Used as battery-to-busbar and battery-to-stud-terminal cabling for portable power stations, off-grid solar systems with stud-terminal charge controllers and inverters, e-bike and e-scooter battery banks, UPS retrofits, RV house-battery distribution, and bench DC supplies where one end plugs into an XT60 pack interface and the other bolts directly to a threaded stud.
  • Custom wire gauge (816 AWG), overall length, silicone or PVC insulation, ring lug stud size (M4, M5, M6, M8, M10, or AWG-style 1/4 in / 5/16 in / 3/8 in), red/black or all-black configuration, and inline ATC fuse holder available on request submit a quote request for non-stock builds.
