- HP: 5
- RPM: 1725
- Volts: 230
- Amps: 23/25
- Hz: 60
- Phase: 1
- Frame: 184TC
- Enclosure Type: Open
- Enclosure Material: Steel
- Mounting: C-Face/Rigid
- Shaft Diameter: 1.125″
- Overall Length: 16.5″
- Rotation: Reversible
- Number of Speeds: 1
- Service Factor: 1.15
- Bearings: Ball
- Efficiency: 82.5%
- Thermal Protection: Manual
- Maximum Ambient Temperature: 40° C
- Insulation Class: F
- Duty Cycle: Continuous
- Manufacturer Model : 36F484W903
- Ship Weight: 88 lbs.
