Elecbrakes Trailer Wired Leader
Includes:1x Trailer Wired Leader
Details:Wiring harness for custom installations, providing water proof IP67 connector to the brake controller.
Leader pre-wired with Deutsch plug to suit both ELBC2000-PS and EB2 units. This leader can be internally routed through the trailer chassis as required.
– It is possible to hardwire an Elecbrakes Trailer-Wired-Leader (TWL) directly to the trailer plug or harness. Wiring diagram available Here
– When using a 7 pin plug/socket, an optional light duty auxiliary may be provided via Pin 2, suitable for up to 15 amp capacity when factoring the combined lighting circuit current draw.
– Elecbrakes brake controllers are compatible with 12V and 24V DC vehicles, requiring a minimum input of 10V. The functional input voltage ensures that there is adequate power received from the tow vehicle to engage the brakes appropriately.
