Built to handle daily tire service with consistency, the Katool KT-T810 & KT-B750 Combo combines a powerful tire changer with a precision wheel balancer into one complete setup. This pairing is designed for automotive shops, tire service bays, and garages that need reliable performance for both mounting and balancing without slowing down workflow.
The KT-T810 tire changer focuses on durability and ease of use, featuring a strong motor, hardened components, and user-friendly pedal controls that simplify tire removal and installation. Paired with the KT-B750 balancer, which delivers accurate readings with fast cycle times, this combo supports efficient service from start to finish.
Together, these machines provide a balanced solution for handling passenger vehicles and light truck wheels, helping maintain consistent results while supporting day-to-day shop productivity.
What’s Included
- Katool KT-T810 Tire Changer
- Katool KT-B750 Wheel Balancer
KT-T810 Tire Changer
| Specifications | Details |
|---|---|
| Max Wheel Diameter | 41″ / 1040 mm |
| Max Wheel Width | 15″ / 380 mm |
| Outside Clamp Range | 12″ 22″ |
| Inside Clamp Range | 14″ 24″ |
| Power Supply | 120V / 1PH |
| Motor Power | 2.0 HP / 1.5 kW |
| Rotation Speed | 6.8 rpm |
| Air Pressure | 0.8 1.0 MPa (116145 psi) |
| Net Weight | 186 kg |
| Warranty | 12-Month Parts Warranty |
KT-T810 Key Features
- 2.0 HP Motor Consistent power with copper winding for durability
- Alloy Steel Jaws Carburized and hardened for strong clamping grip
- Stainless Steel Mounting Head Includes protective cover to help reduce rim contact
- Pedal-Controlled Inflation System Hands-free operation for efficiency
- Bead Blast Seater Assists with fast and secure tire seating
- Pull-Type Pedal Controls Simplifies operation and maintenance
- Protective Components Spade cover and jaw protectors help reduce rim damage
- Closed-Body Design Shields internal components for longer service life
- Integrated Air Filter System Helps maintain pneumatic performance
KT-B750 Wheel Balancer
| Specifications | Details |
|---|---|
| Rim Diameter | <30" |
| Wheel Width | Up to 15″ |
| Max Wheel Diameter | <34.6" |
| Max Wheel Weight | <65 kg |
| Balancing Speed | 180 rpm |
| Balancing Accuracy | 1 g |
| Measuring Time | ~7 seconds |
| Power Supply | 120V / 1PH |
| Motor Power | 0.25 kW |
| Center Hole Diameter | <135 mm |
| Warranty | 12-Month Parts Warranty |
KT-B750 Key Features
- 1g Balancing Accuracy Supports precise wheel correction
- Fast Measuring Cycle (7s) Improves workflow efficiency
- Automatic Measurement Input Streamlines setup with A/D data entry
- Multiple Balance Modes Adapts to different rim types
- Self-Calibration System Built-in diagnostics for consistent accuracy
- Reinforced Steel Frame Reduces vibration during operation
- High-Strength Shaft (Quenched) Designed for durability
- Advanced Circuit Board Moisture-resistant and anti-static design
- Unit Selection Options Ounce/Gram and MM/Inch settings
- Extended Shaft Design Supports wider wheel applications
Documents
- KT-T810 Manual
- KT-B750 Manual
