Trundles Universal DIY Small Alloy Airbox Kit
Notes:– If you have selected a blank outlet, a Trundles 3″ Pod Filter will be supplied unless otherwise requested
– In dusty and muddy environments we recommend running apre-filter wrapon pod filter
– Please use the drop-down menu to select your preferred inlet and outlet size
– Inlet size refers to the snorkel/intake pipe to airbox hole
– Outlet size refers to the engine intake manifold/turbo to airbox hole
Dimensions Once Completed:– 240mm Long– 195mm Tall (With Lid)– 187mm Deep
Details:– This kit come with all pieces needed to weld up your own universal airbox– Comes with 8mm plate with holes ready to be tapped
COMPONENTS
1x Base Folded and Drilled, Top Plate, Acrylic Lid
1x Gasket to suit Acrylic Lid
1x Washer/Bolt kit
2x End caps (either a 3″, 4″ or no hole depending on specification selected)
2x Pieces of Pipe (if opting for blank end caps, please advise if you would like 3″ or 4″ pipe for your inlet and outlet in checkout notes)1x Trundles POD filter to suit hole in end caps (if opting for blank end caps, please advise what size you would like in checkout notes)
