Overview
The UTS5000A-AMK adds channel power, occupied bandwidth, ACPR, C/N, and other standard RF measurements for transmitter and amplifier characterization. The option is enabled by a software license keyed to the spectrum analyzer’s serial number and is permanent for the life of the instrument.
Key Features
- Channel Power Total power within a defined channel bandwidth.
- Occupied Bandwidth Bandwidth containing of transmitted power.
- ACPR/ACLR Adjacent channel power ratio for spectral regrowth evaluation.
- C/N Ratio Carrier-to-noise for link budget and receiver sensitivity.
- Lifetime License Activation activate once, owned for the life of the instrument. No subscriptions, no renewals, no maintenance fees.
When You Need This Option
The option fits the following workflows:
- Transmitter Characterization Measure channel power, OBW, and ACPR for regulatory compliance.
- Amplifier Testing Evaluate PA linearity via ACPR at various power levels.
Compatibility
This option is compatible with all UTS5000A Series spectrum analyzers. The same capability is offered on other UNI-T spectrum analyzer families: UTS1000B, UTS3000A, UTS3000B, UTS7000A.
Frequently Asked Questions
How is this option activated?
The option is enabled by a software license keyed to the spectrum analyzer’s serial number. After purchase, the license is registered on the UNI-T website to generate the license file, which is then loaded onto the spectrum analyzer from a USB drive through the option-install menu. Refer to the spectrum analyzer’s user manual for the step-by-step procedure.
Is the license permanent, or does it require renewal?
The license is permanent a one-time purchase that stays active for the life of the instrument. No subscriptions, no annual renewals, and no expiration.
